OptiBreaker Plus 12
Up to 144,000 eggs/hour Up to 400 cases/hour
Performance egg breaker, with high production yield, best-in-class separation, and a highly hygienic system.
The Plus 12 model processes up to 144.000 eggs/hour (400 cases/hour), a great fit for medium-sized breaking & separation operations.
The 12-row egg-breaking compartment with 216 optimized cracker units serves 432 receiving and separation cups. Cam-controlled breaker bars allow for the longest possible draining time, maximizing product yield and quality. The machine comes equipped with the OptiManagement system, offering automatic fault tracing, detailed service surveillance with update alarms, and a computer-vision-based egg yolk scanning system. The intelligent automatic cup washing and air purging system ensures optimal cleanliness and efficiency.
Liquid egg is collected at the bottom of the machine via product outlets, while eggshells are hygienically ejected through a built-in sanitary screw conveyor. The machine's speed is controlled by a frequency inverter for optimal efficiency.
The Plus series features a standard integrated CIP (cleaning-in-place) system, reducing the need for manual cleaning and lowering labor costs. Maintenance is simplified with features like snap-on/off receiving and separation cups, easily changeable cracker units, and large door dimensions for quick access. An optional cam installation under the cups allows for manual inspection.
Key features:
- Long draining time for maximum yield
- Advanced computer-vision egg yolk scanning
- Intelligent cup-washing system
- Real-time monitoring of machine performance
- Integrated CIP system for reduced cleaning time and labor
- Easy maintenance with snap-on/off cups and changeable cracker units
- Large door dimensions for convenient accessibility and optional cam inspection
The OptiBreaker Plus Series is your solution for world-class egg processing operations.
Specifications
- In-line capacity
- 400 cases/hour
- 144,000 eggs/hour
- Loader type
- OptiLoader PLUS 12
- JW 12
- AquaLoader 12
- Off-line capacity with OptiLoader
- 400 cases/hour
- 144,000 eggs/hour
- Off-line capacity with JW 12
- 300 cases/hour
- 108,000 eggs/hour
- Off-line capacity with AquaLoader 12
- 300 cases/hour
- 108,000 eggs/hour
