Tray Washer - In-line STW-12/18

Features

• Installation Options

  • Left, right or straight conveying system for washed trays
  • Direct or indirect steam heating or electrical heating of wash water
  • Sanitiser spraybar for sanitising of washed trays
  • Automatic loading of trays
  • CIP cleaning
  • Separate washer module for after rinsing






• Washing with power nozzles

  In the wash chamber, power nozzles are placed closely above and underneath the trays. By spraying a large volume of pressurised water, the dirt on the trays is simply blasted off. No dirt will remain on the trays after the power nozzles have done their work. The water is filtered and recycled to minimise the use of fresh water. After washing, the trays can be disinfected by a sanitiser spray bar.

• Reducing operation costs

  The SANOVO STW-12/18 has been designed with the primary goal in mind – to reduce operating costs by substantial cuts in the manpower needed. Including high capacity, top-class washing performance and low energy costs - the payback time of the tray washer is short.



• Dry trays improve hygiene

  The spinner has a speed of 840 rpm, leaving the trays absolutely dry and ready for use.



• Performance monitoring

  The entire washing operation is easily controlled from a touch display. Parameters such as speed, spinning time, etc., may be changed simply by pressing one of the pictograms and entering the desired value.

  During production, the performance, as well as speed, run time, down time, number of trays washed, spinning time, error codes etc., is continuously shown on the display. SANOVO STW-12/18 is equipped with two local operator panels on the washer and one local operator panel on the spinner for start/stop, reset and emergency stop.
